PNVM
Night Vision Monocular with adaptable enough to function in various lighting and weather conditions
II Tube Base Sight
Night Vision Monocular with adaptable enough to function in various lighting and weather conditions
The PNVM is a monocular device designed specifically for night vision applications, enabling users to visualise pictures in extreme low light conditions.
Indicator
It has an IR indicator and a low battery indicator.
Field of View
It provides a field of view upto 10 degree with error of 1 degree.
Eye-Relief
The device eye relief is upto 24mm.
II Tube
It is equipped with Gen-2 Image Intensifier Tubes.
Type of Attachment
This monocular can be used with a head mount or hands-free.
| Eletro-Mechanical Characteristics | |
|---|---|
| Weight | 900 grams (+/-50 grams) |
| Power Source | CR 123A |
| Operating Time | More than 15 hours |
| Start up time | < 1 sec |
| Dimensions | 250 x 75 x 130 |
| Ingress Protection | IP 67 |
| Low Battery and IR Indicator | Yes |
| Operating Temperature | -40° to +50°C |
| High Light Cut off | Yes |
| Packaging | Hard Case |
| Imaging Characteristics | |
|---|---|
| Image Intensifier Tube | Gen II / Gen II+ / Gen III |
| Resolution | 47 - 64 LP/mm |
| SNR | 18 - 22 dB |
| Magnification | 1X - 6X |
| Field of View | 10 Degree +/- 1 Degree |
| Range of Focus | 5 m to infinity |
| Interpupillary Distance | Yes, 55-71 mm |
| Eye Relief | 24mm |
| Diopter | -5D to +2 |
| Dimensions (mm) L x W x H | 144 x 69 x 63 |
| Focal Length | 25 mm |
| Environmental STD | MIL STD 810G |
